ACSR — ALUMINUM CONDUCTOR STEEL REINFORCED
Email Page
Search
Toggle Icon

Aluminum Building Wire

Category Link Icon
Toggle Icon

Type MC Aluminum Armored Cables

Category Link Icon
Toggle Icon

Utility Aluminum Cables

Category Link Icon
Toggle Icon

Aluminum URD Cables (Underground)

Category Link Icon
Toggle Icon

Service Drop Cables (Overhead)

Category Link Icon
Toggle Icon

Aluminum Service Drop Cables - Quadruplex

Category Link Icon
Toggle Icon

Aluminum Service Drop Cables - Triplex

Category Link Icon
Toggle Icon

Aluminum Service Drop Cables - Duplex

Category Link Icon
Toggle Icon

Bare Aluminum Cables

Category Link Icon
Toggle Icon

SO Portable Cord Cables

Category Link Icon
Compare Products
Back
Add to Quote
Codeword

Size
(AWG or kcmil)

Stranding
(Al/Stl)

 Wire Diameter Diameter Weight

Rated Strength
(lbf)

DC Resistance
@ 20 deg C
(ohm / 1000 ft)

Ampacity
(A)

Aluminum
(in)

Steel
(in)

Steel Core
(in)

Overall
(in)

Aluminum
(lb / 1000 ft)

Steel
(lb / 1000 ft)

Net
(lb / 1000 ft)
Grouse 80 8/1 0.1000 0.1670 0.1670 0.367 75.0 73.9 148.9 5200 0.206 206
Petrel 101.8 12/7 0.0921 0.0921 0.2763 0.461 95.9 157.9 253.8 10400 0.158 234
Minorca 110.8 12/7 0.0961 0.0961 0.2883 0.481 104.4 171.9 276.3 11300 0.145 245
Leghorn 134.6 12/7 0.1059 0.1059 0.3177 0.530 126.8 208.7 335.5 13600 0.120 271
Guinea 159 12/7 0.1151 0.1151 0.3453 0.576 149.7 246.6 396.3 16000 0.101 296
Dotterel 176.9 12/7 0.1214 0.1214 0.3642 0.607 166.6 274.3 440.9 17300 0.0911 313
Dorking 190.8 12/7 0.1261 0.1261 0.3783 0.631 179.7 296.0 475.7 18700 0.0845 326
Brahma 203.2 16/19 0.1127 0.0977 0.4885 0.714 191.4 483.2 674.6 28400 0.0764 341
Cochin 211.3 12/7 0.1327 0.1327 0.3981 0.664 199.0 327.8 526.8 20700 0.0763 344
Turkey 6 6/1 0.0661 0.0661 0.0661 0.198 24.5 11.6 36.1 1190 0.641 105
Swan 4 6/1 0.0834 0.0834 0.0834 0.250 38.9 18.4 57.3 1860 0.403 139
Swanate 4 6/1 0.0772 0.1029 0.1029 0.257 38.9 28.0 66.9 2360 0.399 139
Sparrow 2 6/1 0.1052 0.1052 0.1052 0.316 61.9 29.3 91.2 2850 0.254 184
Sparate 2 6/1 0.0974 0.1299 0.1299 0.325 61.9 44.7 106.6 3640 0.251 184
Robin 1 6/1 0.1181 0.1182 0.1182 0.355 78.1 37.0 115.1 3550 0.201 211
Raven 1/0 6/1 0.1327 0.1327 0.1327 0.398 98.5 46.6 145.1 4380 0.159 243
Quail 2/0 6/1 0.1489 0.1489 0.1489 0.447 124.1 58.7 182.8 5310 0.126 278
Pigeon 3/0 6/1 0.1672 0.1672 0.1672 0.502 156.4 74.0 230.4 6620 0.100 319
Penguin 4/0 6/1 0.1878 0.1878 0.1878 0.563 197.4 93.4 290.8 8350 0.0795 366
Waxwing 266.8 18/1 0.1217 0.1217 0.1217 0.609 249.9 39.2 289.1 6880 0.0643 449
Partridge 266.8 26/7 0.1013 0.0788 0.2364 0.642 251.3 115.6 366.9 11300 0.0637 457
Ostrich 300 26/7 0.1074 0.0835 0.2505 0.680 282.5 129.7 412.2 12700 0.0567 492
Merlin 336.4 18/1 0.1367 0.1367 0.1367 0.683 315.3 49.5 364.8 8680 0.0510 519
Linnet 336.4 26/7 0.1137 0.0884 0.2652 0.720 316.6 145.4 462.0 14100 0.0505 529
Oriole 336.4 30/7 0.1059 0.1059 0.3177 0.741 317.7 208.7 526.4 17300 0.0502 535
Chickadee 397.5 18/1 0.1486 0.1486 0.1486 0.743 372.5 58.5 431.0 9940 0.0432 576
Brant 397.5 24/7 0.1287 0.0858 0.2574 0.772 374.4 137.0 511.4 14600 0.0430 584
Ibis 397.5 26/7 0.1236 0.0961 0.2883 0.783 374.1 171.9 546.0 16300 0.0428 587
Lark 397.5 30/7 0.1151 0.1151 0.3453 0.806 375.3 246.5 621.8 20300 0.0425 594
Pelican 477 18/1 0.1628 0.1628 0.1628 0.814 447.1 70.2 517.3 11800 0.0360 646
Flicker 477 24/7 0.1410 0.0940 0.2820 0.846 449.4 164.5 613.9 17200 0.0358 655
Hawk 477 26/7 0.1354 0.1053 0.3159 0.858 449.0 206.4 655.3 19500 0.0356 659
Hen 477 30/7 0.1261 0.1261 0.3783 0.883 450.4 296.0 746.4 23800 0.0354 666
Osprey 556.5 18/1 0.1758 0.1758 0.1758 0.879 521.4 81.8 603.3 13700 0.0308 711
Parakeet 556.5 24/7 0.1523 0.1015 0.3045 0.914 524.3 191.8 716.1 19800 0.0307 721
Dove 556.5 26/7 0.1463 0.1138 0.3414 0.927 524.2 241.0 765.2 22600 0.0305 726
Eagle 556.5 30/7 0.1362 0.1362 0.4086 0.953 525.4 345.2 870.7 27800 0.0303 734
Peacock 605 24/7 0.1588 0.1059 0.3177 0.953 570.1 208.7 778.8 21600 0.0282 760
Squab 605 26/7 0.1525 0.1186 0.3558 0.966 569.5 261.8 831.3 24300 0.0281 765
Wood Duck 605 30/7 0.1420 0.1420 0.4260 0.994 571.2 375.3 946.5 28900 0.0279 773
Teal 605 30/19 0.1420 0.0852 0.4260 0.994 571.2 367.4 938.6 30000 0.0279 773
Kingbird 636 18/1 0.1880 0.1880 0.1880 0.940 596.3 93.6 689.9 15700 0.0270 773
Swift 636 36/1 0.1329 0.1329 0.1329 0.930 596.0 46.8 642.8 13800 0.0271 769
Rook 636 24/7 0.1628 0.1085 0.3255 0.977 599.1 219.1 818.2 22600 0.0269 784
Grosbeak 636 26/7 0.1564 0.1216 0.3648 0.990 599.0 275.2 874.2 25200 0.0267 789
Scoter 636 30/7 0.1456 0.1456 0.4368 1.019 600.5 394.6 995.1 30400 0.0266 798
Egret 636 30/19 0.1456 0.0874 0.4370 1.019 600.5 386.7 987.2 31500 0.0266 798
Flamingo 666.6 24/7 0.1667 0.1111 0.3333 1.000 628.2 229.7 857.9 23700 0.0256 807
Gannet 666.6 26/7 0.1601 0.1245 0.3735 1.014 627.7 288.5 916.2 26400 0.0255 812
Stilt 715.5 24/7 0.1727 0.1151 0.3453 1.036 674.2 246.6 920.8 25500 0.0239 844
Starling 715.5 26/7 0.1659 0.1290 0.3870 1.051 674.0 309.7 983.7 28400 0.0238 849
Redwing 715.5 30/19 0.1544 0.0926 0.4630 1.081 675.3 434.0 1109.3 34600 0.0236 859
Coot 795 36/1 0.1486 0.1486 0.1486 1.040 745.1 58.5 803.6 16800 0.0217 884
Cuckoo 795 24/7 0.1820 0.1213 0.3639 1.092 748.8 273.9 1022.6 27900 0.0215 901
Drake 795 26/7 0.1749 0.1360 0.4080 1.108 749.1 344.3 1093.4 31500 0.0214 907
Tern 795 45/7 0.1329 0.0886 0.2658 1.063 748.6 146.1 894.7 22100 0.0216 887
Condor 795 54/7 0.1213 0.1213 0.3639 1.092 748.4 273.9 1022.2 28200 0.0215 889
Mallard 795 30/19 0.1628 0.0977 0.4885 1.140 750.7 483.2 1234 38400 0.0213 917
Ruddy 900 45/7 0.1414 0.0943 0.2829 1.131 847.4 165.5 1013 24400 0.0191 958
Canary 900 54/7 0.1291 0.1291 0.3873 1.162 847.7 310.2 1157.9 31900 0.0190 960
Rail 954 45/7 0.1456 0.0971 0.2913 1.165 898.5 175.5 1074 25900 0.0188 993
Cardinal 954 54/7 0.1329 0.1329 0.3987 1.196 898.3 328.7 1227.1 33800 0.0179 996
Ortolan 1033.5 45/7 0.1515 0.1010 0.3030 1.212 972.8 189.9 1162.7 27700 0.0166 1043
Curlew 1033.5 54/7 0.1383 0.1383 0.4149 1.245 972.8 356.0 1328.8 36600 0.0165 1047
Bluejay 1113 45/7 0.1573 0.1049 0.3147 1.259 1048.7 204.8 1253.6 29800 0.0155 1092
Finch 1113 54/19 0.1436 0.0862 0.4310 1.293 1053.9 376.1 1430.1 39100 0.0154 1093
Bunting 1192.5 45/7 0.1628 0.1085 0.3255 1.302 1123.4 219.1 1342.5 32000 0.0144 1139
Grackle 1192.5 54/19 0.1486 0.0892 0.4460 1.338 1128.6 402.8 1531.4 41900 0.0144 1141
Bittern 1272 45/7 0.1681 0.1121 0.3363 1.345 1197.7 233.9 1431.6 34100 0.0135 1184
Pheasant 1272 54/19 0.1535 0.0921 0.4605 1.382 1204.3 429.4 1633.7 43600 0.0135 1187
Dipper 1351.5 45/7 0.1733 0.1155 0.3465 1.386 1272.9 248.3 1521.2 36200 0.0127 1228
Martin 1351.5 54/19 0.1582 0.0949 0.4745 1.424 1279.1 455.9 1735 46300 0.0127 1231
Bobolink 1431 45/7 0.1783 0.1189 0.3567 1.427 1347.5 263.1 1610.6 38300 0.0120 1272
Plover 1431 54/19 0.1628 0.0977 0.4885 1.465 1354.6 483.2 1837.8 49100 0.0120 1275
Nuthatch 1510.5 45/7 0.1832 0.1221 0.3663 1.466 1422.5 277.5 1700 40000 0.0114 1313
Parrot 1510.5 54/19 0.1672 0.1003 0.5015 1.505 1428.8 509.2 1938.1 51700 0.0114 1317
Lapwing 1590 45/7 0.1880 0.1253 0.3759 1.504 1498.1 292.2 1790.3 42200 0.0108 1354
Falcon 1590 54/19 0.1716 0.1030 0.5150 1.545 1505.0 537.0 2042.1 54500 0.0108 1359
Chukar 1780 84/19 0.1456 0.0874 0.4370 1.602 1685.4 386.7 2072.1 51000 0.00970 1453
Bluebird 2156 84/19 0.1602 0.0961 0.4805 1.762 2040.4 467.5 2507.9 60300 0.00801 1622
Kiwi 2167 72/7 0.1735 0.1157 0.3471 1.735 2051.4 249.2 2300.5 49800 0.00801 1607
Thrasher 2312 76/19 0.1744 0.0814 0.4070 1.802 2187.9 335.4 2523.3 56700 0.00750 1672
Joree 2515 76/19 0.1819 0.0849 0.4245 1.880 2384.0 364.8 2749 61700 N/A 1751

Notes:

  1. Dimensions and weights are subject to standard manufacturing tolerances and are subject to change without notice.
  2. Resistance is calculated using metal conductivity of 61.2% IACS for EC (1350) at 20ºC and 8% IACS for steel at 20ºC.
  3. Ampacities are based on 75ºC conductor temperature, 25ºC ambient, 2 ft/s wind, full sun, an emissivity of 0.5 and a coefficient of solar absorption of 0.5, at sea level.

Notes:

  1. Dimensions and weights are subject to standard manufacturing tolerances and are subject to change without notice.
